Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)
American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 30
train of gears will give 1,000 yards. The 1 rep-resents 1 revolution of the worm, which is also 1 revolution ofthe measuring roll, and that being 12 inches in circumference willmean that 12 inches of yarn has been placed on the beam during1 revolution of the worm, or 1 tooth of the first 48… … WARP PREPARATION. 19 or the number of yards in the whole wrap. By the substitutingof the 64 gear below the cut gear the ratio will be equal to 4 to 1.Thus the number of teeth in the gear B will be 4 times greaterthan the number of cuts in the leese. Example. We require 1,000 yards of j^arn on the…
Weaving
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
