Collins, Charles Dickey, 1872- (from old catalog) · New York, D. Van Nostrand company · leaf 63
of thepropeller through the surrounding medium, therebyreducing the propeller horsepower. Warp: To change the form of the wing by twisting it,usually by changing the inclination of the rear sparrelative to the front spar. Wings : The main supporting surfaces of an airplane. Wing loading: The weight… … HYDROAIRPLANEOR SEAPLANE (PU5HCR TYPO STANDARD COLUMN (OEP^CONTROL No. 8-Engine 9-Propeller 10-Obeservers or passengers seat 11-Pilots seat 12-Longeron6-Horizontal stabilizer 13-Fuselage strut7-Wheel 14 A-Fuselage truss wire No. 1-Upper plane lA- Lower plane 2-Fuselage or body 3-Rudder 4-Elevator…
Drawing-room practice · Mechanical drawing
Internet Archive Book Images · The Library of Congress · No known copyright restrictions (public domain). Free to use for anything.
