Practical engineering drawing and third angle projection, for students in scientific, technical and manual training schools and for ... draughtsmen .. (1897)
Willson, Frederick Newton, 1855-1939 · Princeton, N.J., The author · leaf 102
ens have been prepared by F. Soennecken. The pens are stubs of various widths, cut off obliquely, and when inuse should not, as ordinarily, be dipped into the ink, butthe latter should be inserted, by means of another pen,between the top of the Soennecken pen and the brassfeeder that is usually… … 96 THEORETICAL AND PRACTICAL GRAPHICS. V ~:l 51 4i3 ffi / u 266. Bordeis. Another effective adjunct to a map or other drawing is a neat border. It shouldbe strictly in keeping with the drawing, both as to character and simplicity. On page 95 a large number of corner designs and borders is…
Mechanical drawing · Lettering
Internet Archive Book Images · No known copyright restrictions (public domain). Free to use for anything.
