Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 411
Fig. 257. View of Truck Sliowing Spring Supports for Motor The New Haven locomotives enter New York on the New YorkCentral tracks and have thus to operate on direct current. For-tunately the alternating-current series motor is well adapted todirect current. When operating thus the motors are… … Fig. 258. View of Hollow Armature Shaft and Pin Plate Current is normally taken from the trolley wire through apantagraph as shown in Fig. 259, which shows the complete loco- 8«6 ELECTRIC RAILWAYS 269
Electrical engineering
Internet Archive Book Images · Northeastern University, Snell Library · No known copyright restrictions (public domain). Free to use for anything.
