e exactly opposite to the eye, or the pointin which a perpendicular from the eye falls on the plane.In the ground plane draw V W parallel to A D; its per-spective v w will be parallel to a d in the picture, and adwvwill be the perspective of the part A D W V in the originalplane. We shall now… … plane VGKC, contiguous to, and at right angles with, theperspective plane YZSE. F H is the distance of the plane,and H I the height of the eye at I. HE is parallel to G Bor C K, and bisects A D and B C in the points F and E. Onthe point E raise the perpendicular E M, equal to H I, anddraw the lines…
