A Dictionary of science, literature, and art [electronic resource]: comprising the history, description, and scientific principles of every branch of human knowledge; with the derivation and definition of all the terms in general use (1844)

Brande, William Thomas, 1788-1866, Cauvin, Joseph · New York : Harper & brothers · leaf 931

An illustration from A Dictionary of science, literature, and art [electronic resource]: comprising the history, description, and scientific principles of every branch of human knowledge; with the derivation and definition of all the terms in general use, 1844, leaf 931
g point of all lines parallel to o e. as will be B ofall lines parallel to eb. E is the place of the eye at theintersection of the ground plane with the picture, being aperpendicular from A B to E. If H H be the horizontalline, then HE, equal to A E, is the place of the eye onthe perspective plane.… … which will be the boundaries of the sides ae and eb re-spectively. On the plan continue one of the sides a e tillit intersects the picture in h, and make C h on the perspec-tive plane equal to A A on the plan ; and draw the verticalh h, which will be the line of heights on vyhich they areto be set…
