Bridges and culverts for highway traffic, flat slab and girder type ... (1908)
Expanded Metal and Corrugated Bar Company · Expanded Metal and Corrugated Bar Company · leaf 32
nds.Bend up one bar 66 from end and two bars $$ from abutment.Stirrups: use _■ corrugated rounds same spacing as in G3. Bearing of Bridge on Abutment—In order to properly distri-bute the load and provide for sufficient bearing area the bridgewill be made solid for the full depth of the girders,… … II
Concrete · Bridges · Culverts
