Application of a Silicon Compiler to VLSI (Very Large Scale Integrated Circuits) Design of Digital Pipelined Multipliers (1984)

Defense Technical Information Center · leaf 26

An illustration from Application of a Silicon Compiler to VLSI (Very Large Scale Integrated Circuits) Design of Digital Pipelined Multipliers, 1984, leaf 26 — Piguxe 2.3 Floor Plan of the BacPitts Target Architecture. The data path portion of the layout consists of a rectangular array of units called "organelles." An orga¬ nelle is a tit- vise functional unit. A standard library of functions— adder, subtracter, shifters, increaenters, ccnpa- xatoxs, etc.…

Carlson,D J · Naval postgraduate school monterey ca · Integrated circuits · Silicon · Compilers · Digital computers · INPUT · Output · Digital systems · Isolation · Theses · Storage

Internet Archive · Defense Technical Information Center · Public domain (US government work). Free to use for anything.
