Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills (1921)

M.H. Detrick Company. · M.H. Detrick Co. · leaf 34

An illustration from Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills, 1921, leaf 34 — Erie City Boiler and Bagasse Furnace with Double Arch lllllllliiilllllilllllllllllilllllll Page Thirty-two DETRICR … ARCHES Hand-Fired Refuse Burner with Stirling Boiler No Special or Cut Tile Needed Around Spout

Building materials · Masonry · Refractory masonry · Flat arch

Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
