Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills (1921)
M.H. Detrick Company. · M.H. Detrick Co. · leaf 7
le is hooked on to the adjacent tile, and is not carried onthe arch bar. Because of this construction, the end tile can be made small. Theend of the arch-bar is well protected from the heat. The apron wall is supported by a shelf casting, independently of the end tile. Anyend tile can be removed… … Page Six lillllllllllllllllll Allium DETRICR
Building materials · Masonry · Refractory masonry · Flat arch
