Mortars, plasters, stuccos, artificial marbles, concretes, portland cements and compositions (1906)

Fred T. Hodgson · Frederick J. Drake and Co. · leaf 200

An illustration from Mortars, plasters, stuccos, artificial marbles, concretes, portland cements and compositions, 1906, leaf 200
and F C are the top andbottom flute collars fixed on the brick core of the coin:z ..D R is the main diminished floating rule in positi. n forforming the main contour or fillet line of the colum::.This rule is rebated at the top to allow for a bearing onthe top as well as on the edge of the collar.… … Forming Fluted Columns—Collar Method. no. 12. floating rule in position when forming the flutes. Theends of this rule as shown bear on the back surface ofa flute as indicated by the dotted lines. A portion of theastragal moulding, A, with a part of the shaft is shown METHODS Of WOKK 199 so as to…
