General catalogue of E.L. Roberts & Co., wholesale manufacturers of doors, glazed sash, blinds: no. 600 (1908)
E.L. Roberts & Co. · E.L. Roberts & Co. · leaf 174
ELEVATION DETAILS OF R 862^ n1fflWtt, In above details the following designs are employed:iex^on ™lumnV^fi^iuSTO?/7 M R1937MTop rail, R1944M; Bottom rail, R1946J/£. Balcony baluster, 1U87UH-Read pages 211 to 213, regarding porch work. E. L. ROBERTS & CO., CHICAGO. 219 CLASSIC PORCH DESIGN. See… … COMPLETE ELEVATION OF DESIGN R 1862 H- The details on opposite page are carefully drawn to a scale, and the total height from porch floor to top of balcony newel is divided into 23 equal divisions. These divisions show the proportionate relations of columns, entablature and balcony balustrade to…
Woodwork · Sashes · Doors · Wood base and shoe moldings · Exterior wood shutters · Wood stairs · Wood railings · Wood posts and columns · Wood mantels · Panel doors · Wood Doors · Wood stile and rail doors · Wood Windows · Art glass
