en mill out the centreportion with a single cutter. When thiswork is complete, they can be transferredto another jig and milling machine andhave the outside surfaces of the jawsmilled. This being done, the next thing to do isto mill the lug to the required angle, be-tween milling cutters, and then… … CHAPTER XI THE TAIL PLANE. The tail plane will now have to be con-sidered. For the purpose of this articleone may assume that the tail plane is al-most semi-circular in shape and that theframework is formed of light steel tubing.This will be in four lengths; the first piecebeing straight, and…
Airplanes
