STRUT ( O ) SHOE … STRUT SKETCH SHOWING STRUT SHOE IN PLACEFig. 27. to fit the longeron and also to form the lugto which is attached the stay tube. Theedges of the two pieces forming the lug154 HOW AN AEROPLANE IS BUILT are brazed together, with the addition ofa small washer on either side, the holeafterwards being…
