The power of form applied to geometric tracery : one hundred designs and their foundations resulting from one diagram (1851)

Billings, Robert William, 1813-1874 · W. Blackwood and Sons · leaf 85

An illustration from The power of form applied to geometric tracery : one hundred designs and their foundations resulting from one diagram, 1851, leaf 85
Here the circles 1 and 3 are repetitions. LVI. … In this example No. 2 is a repetition of 1, and 3 and 4 are equal circles. In theminor tracery all the foil heads are repetitions of one circle.

Decoration and ornament · Geometry in art · Geometry in architecture · Architectural design · Form (aesthetics) · Geometrical drawing

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
