Investigation of a 1/4-Scale Model of the Republic F-105 Airplane in the Langley 19-Foot Pressure Tunnel. Influence of Trailing-Edge Flap Span and Deflection on the Longitudinal Characteristics (1954)

NASA Technical Reports Server (NTRS) · leaf 16

An illustration from Investigation of a 1/4-Scale Model of the Republic F-105 Airplane in the Langley 19-Foot Pressure Tunnel. Influence of Trailing-Edge Flap Span and Deflection on the Longitudinal Characteristics, 1954, leaf 16
NA.CA RM SL54H2?.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
