An Investigation of the Characteristics of Steel Diaphragms for Automatic Fuel-Injection Valves (1926)
NASA Technical Reports Server (NTRS) · leaf 30
Multiple thickness in inches. Fig,9 Pressure variation with change of multiple tnickness taken at a deflection of 0.008 inch fcr all diaphragms.NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
