Pressure distribution over a Douglas wing tip on a biplane in flight (1930)

NASA Technical Reports Server (NTRS) · leaf 30

An illustration from Pressure distribution over a Douglas wing tip on a biplane in flight, 1930, leaf 30 — Fig.7 Rib vs rib CN for rib A,with, experimental points.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
