The N.A.C.A. Apparatus for Studying the Formation and Combustion of Fuel Sprays and the Results from Preliminary Tests (1931)

NASA Technical Reports Server (NTRS) · leaf 34

An illustration from The N.A.C.A. Apparatus for Studying the Formation and Combustion of Fuel Sprays and the Results from Preliminary Tests, 1931, leaf 34
5afefy ft/?/ Tig, 13 Effect of physical properties of fuel on spray formation. Injection ▼aire in vertical positi Injection pressure, 4000 lb. per sq. in. Engine speed, 1500 r.p.m.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
