The pressure distribution over a long elliptical wing tip on a biplane in flight (1932)

NASA Technical Reports Server (NTRS) · leaf 9

An illustration from The pressure distribution over a long elliptical wing tip on a biplane in flight, 1932, leaf 9 — 1 chord 2> … Jig.l M-3 wing with pressure ribs and orifice locationB* (Long allipUcal tip)

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
