Complete tank tests of two flying-boat hulls with pointed steps - N.A.C.A. Models 22-A and 35 (1934)

NASA Technical Reports Server (NTRS) · leaf 40

An illustration from Complete tank tests of two flying-boat hulls with pointed steps - N.A.C.A. Models 22-A and 35, 1934, leaf 40 — Ca - A/wb3 Figure 13.- Variation of Cr with Ca at best Figure 15.- Variation of A/R trim angles. Model 22~A with Ca at best trim angles. Model 22-A

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
