Complete tank tests of two flying-boat hulls with pointed steps - N.A.C.A. Models 22-A and 35 (1934)

NASA Technical Reports Server (NTRS) · leaf 44

An illustration from Complete tank tests of two flying-boat hulls with pointed steps - N.A.C.A. Models 22-A and 35, 1934, leaf 44
Figure 18, - Resistance and trimming moment, r=7°. Model 35

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
