Aerodynamic tests of a low aspect ratio tapered wing with various flaps, for use on tailless airplanes (1933)

NASA Technical Reports Server (NTRS) · leaf 8

An illustration from Aerodynamic tests of a low aspect ratio tapered wing with various flaps, for use on tailless airplanes, 1933, leaf 8 — H.A.C.A. Technical ffote Vo.463 Tig.3 … OLf degrees Tlgore C^.aad c.p. with, full span plain flap set at -various angles

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
