Full-scale Wind-tunnel and Flight Test of a Fairchild 22 Airplane Equipped with a Zap Flap and Zap Ailerons (1937)

NASA Technical Reports Server (NTRS) · leaf 18

An illustration from Full-scale Wind-tunnel and Flight Test of a Fairchild 22 Airplane Equipped with a Zap Flap and Zap Ailerons, 1937, leaf 18 — Figure 1.- Three-view drawing of Zap wing installation on Fairchild 22 airplane.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
