Circulation Measurements About the Tip of an Airfoil During Flight Through a Gust (1939)

NASA Technical Reports Server (NTRS) · leaf 18

An illustration from Circulation Measurements About the Tip of an Airfoil During Flight Through a Gust, 1939, leaf 18 — N.A.C.A. Technical Note No. 685 Figs. 3,7 Figure 7.- Sample oscillograph record of pitch of flow behind air- I foil during passage through gust.
