Hydrodynamic and Aerodynamic Tests of a Family of Models of Seaplane Floats with Varying Angles of Dead Rise - N.A.C.A. Models 57-A, 57-B, and 57-C (1939)

NASA Technical Reports Server (NTRS) · leaf 27

An illustration from Hydrodynamic and Aerodynamic Tests of a Family of Models of Seaplane Floats with Varying Angles of Dead Rise - N.A.C.A. Models 57-A, 57-B, and 57-C, 1939, leaf 27 — 15 3 11 15 3 11 11 15 Trim, deg. Figure 14a.-Model 57-B. Working charts for the determination of resistance and trimming moment.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
