Scavenging a Piston-ported Two-stroke Cylinder (1938)
NASA Technical Reports Server (NTRS) · leaf 43
Figure 27.- Light epring Indicator diagram for exhaust-port of 70° B.B.C. and Inlet-port opening of 52° B.B.C. Compree«lon-ignltion; engine speed, 1,800 r.p.m.NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
