Hydrodynamic Impact Loads on 30 Degree and 60 Degree V-step Plan-form Models with and Without Dead Rise (1958)

NASA Technical Reports Server (NTRS) · leaf 20

An illustration from Hydrodynamic Impact Loads on 30 Degree and 60 Degree V-step Plan-form Models with and Without Dead Rise, 1958, leaf 20 — Figure 8.- Variations of ratio of maximum impact lift coefficients for 30° and 60 V-step models with trim angle. vo

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
