The Bernard 120 seaplane (French) : a 1400 hp single-seat monoplane racer (1931)
NASA Technical Reports Server (NTRS) · leaf 7
Figs .5, 6,7, 8,17,18 N.A.C.A. Aircraft Circular No.139 Fig.5 Duralumin frame under fuselage. Fig.6 Trailing-edge structure with openings for radiator pipes. Fig.7 Fuselage section showing controls and wing attachments. Fig.8 Aileron control.NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
