Air cooling : an experimental method of evaluating the cooling effect of air streams on air-cooled cylinders (1927)

NASA Technical Reports Server (NTRS) · leaf 22

An illustration from Air cooling : an experimental method of evaluating the cooling effect of air streams on air-cooled cylinders, 1927, leaf 22 — r.A.C.A. Technical Memorandum Ho.413 Figs.8 & 9 … Fig.8 Diagram showing relative positions of cylinder and fan duct. Fig. 9 Flan view of cylinder head and fan duct.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
