Slotted-Wing Airplanes (1927)

NASA Technical Reports Server (NTRS) · leaf 12

An illustration from Slotted-Wing Airplanes, 1927, leaf 12
N.A.C.A; Technical Memorandum No.432 Figs.4,5,6. … coefficient Fig.4 Fig.6 3b Center of moments Fig.5. Figs.4,5,6 Functioning of a wing with various auxiliary wings.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
