Spray Penetration with a Simple Fuel Injection Nozzle (1926)
NASA Technical Reports Server (NTRS) · leaf 7
Fig. 6.—Injection pressure, 3,000 lb./sq. in. Chamber pressure, 300 lb./sq. in. Fig. 7.—Injection pressure, 5,000 lb./sq. in. Chamber pressure, 300 lb./sq. in. … Fig. 8.—Injection pressure, 8,000 lb./sq. in. Chamber pressure, 300 lb./sq. in. The original photographs for Figures 3 to 8 inclusive were retouched for reproduction purposes
