Pressure Distribution over a Wing and Tail Rib of a VE-7 and of a TS Airplane in Flight (1928)

NASA Technical Reports Server (NTRS) · leaf 9

An illustration from Pressure Distribution over a Wing and Tail Rib of a VE-7 and of a TS Airplane in Flight, 1928, leaf 9 — 8 REPORT NATIONAL ADVISORY COMMITTEE FOR AERONAUTICS … Fig. 11—Control position record. Pressure distribution test on TS airplane

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
