The N.A.C.A. Photographic Apparatus for Studying Fuel Sprays from Oil Engine Injection Valves and Test Results from Several Researches (1928)
NASA Technical Reports Server (NTRS) · leaf 10
Injection pressure, 8,000 pounds per square inch Chamber pressure, 200 pounds per square inch Ratio of orifice area to groove area, 0.19 Orifice area, 0.000113 square inch Injection pressure, 8,000 pounds per square inch CnamDer pressure, 200 pounds per square inch Ratio of orifice area to groove… … Chamber pressure, atmospheric Injection pressure, 8,000 pounds per square inch Centrifugal spray with secondary discharge after cut-off Chamber pressure, atmospheric Injection pressure, 8,000 pounds per square inch Centrifugal spray with no secondary discharge after cut-off FIG. 7. CENTRIFUGAL…
