Drag and Cooling with Various Forms of Cowling for a "Whirlwind" Radial Air-Cooled Engine I (1930)

NASA Technical Reports Server (NTRS) · leaf 24

An illustration from Drag and Cooling with Various Forms of Cowling for a "Whirlwind" Radial Air-Cooled Engine I, 1930, leaf 24
DRAG A.ND COOLING \ "WHIRLWIND" RADIAL MR-COOLED ENGINE—I … Figure 26.—Cowling No. 10 with slot moved back
