Drag and Cooling with Various Forms of Cowling for a "Whirlwind" Radial Air-Cooled Engine I (1930)

NASA Technical Reports Server (NTRS) · leaf 25

An illustration from Drag and Cooling with Various Forms of Cowling for a "Whirlwind" Radial Air-Cooled Engine I, 1930, leaf 25
REPORT NATIONAL ADVISORY COMMITTEE FOR AERONAUTICS … Figure 29.—No. 4 with engine removed and nose rounded

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
