The Pressure Distribution over the Wings and Tail Surfaces of a PW-9 Pursuit Airplane in Flight (1931)

NASA Technical Reports Server (NTRS) · leaf 9

An illustration from The Pressure Distribution over the Wings and Tail Surfaces of a PW-9 Pursuit Airplane in Flight, 1931, leaf 9 — REPORT NATIONAL ADVISORY COMMITTEE FOR AERONAUTICS Figure S.—Detail view of main instrument installation showing tube connections to manometers

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
