The NACA Tank : A High-speed Towing Basin for Testing Models of Seaplane Floats (1934)
NASA Technical Reports Server (NTRS) · leaf 11
A, Adjustment of hydrovane. P, Light source. B, Bottom chord of roof truss. Q, Mirror. C, Box containing light source and photoelectric cell. R, Rail. D, Bracket for distance tape. S, Reflecting ray. E, Braking rail. T, Rollers. F, Catenary. U, Spring. G, Chair. V, Suspender. H, Damping cylinder.…NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
