Working Charts for the Determination of Propeller Thrust at Various Air Speeds (1935)

NASA Technical Reports Server (NTRS) · leaf 6

An illustration from Working Charts for the Determination of Propeller Thrust at Various Air Speeds, 1935, leaf 6 — WORKING CHARTS FOR THE DETERMINATION OF PROPELLER THRUST AT VARIOUS SPEEDS Figure 6.—Cabin fuselage with J-5 engine and N.A.C.A. engine cowling.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
