Effects of Air-Fuel Spray and Flame Formation in a Compression-Ignition Engine (1937)

NASA Technical Reports Server (NTRS) · leaf 7

An illustration from Effects of Air-Fuel Spray and Flame Formation in a Compression-Ignition Engine, 1937, leaf 7 — Crankshaft degrees Figure 5. .—Effect of air-fiiel ratio on fuel spray and flame formation.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
