The processes in spring-loaded injection valves of solid injection oil engines (1934)

NASA Technical Reports Server (NTRS) · leaf 31

An illustration from The processes in spring-loaded injection valves of solid injection oil engines, 1934, leaf 31 — Crank angle, degrees Figure 10.-Curve of stem travel of the example.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
