Development of Air-cooled Engines with Blower Cooling (1933)
NASA Technical Reports Server (NTRS) · leaf 40
Figs. 15,16,17 N.A.C.A. Technical Memorandum lTo«725 Figure 16.-General view of shrouded single-cylinder engine. … Figure 15.-Single-cylinder engine Figure 17.-Shro^jLd cf single- exposed to free air jet. cylinder engine.NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
