Knowledge Gained from Practical Experience in the Designing of Aircraft Engines (1933)

NASA Technical Reports Server (NTRS) · leaf 39

An illustration from Knowledge Gained from Practical Experience in the Designing of Aircraft Engines, 1933, leaf 39 — N.A.C.A. Technical Memorandum No.706 Figs.19,30 Figure 19.-Blower drives of radial engines.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
