Preliminary Wind-Tunnel and Flight Tests of a Balanced Split Flap, Special Report (1934)

NASA Technical Reports Server (NTRS) · leaf 6

An illustration from Preliminary Wind-Tunnel and Flight Tests of a Balanced Split Flap, Special Report, 1934, leaf 6 — Figurs 1.- Balanced and unbalanced split flaps on Olark Y wing

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
