t on well at the WHEELINGELECTRIC COMPANY plant, carrying l.liHo-ft. span over the Ohio River.The 311,000 CM. copper clad steel transmission cables and ground wire arc-brought over roller saddles. On account of the heavy outward strain due tothe snort distance to the anchor on the Power House, this… … HIGH POLES IX ILLINOIS AND PENNSYLVANIA On the left is shown Pole 90 ft. above foundation, which is 10 ft. abovethe ground, along the Levee at Alton, on the EAST ST. LOUIS &SLBLRBAN RAILWAY COMPANY line to East St. Louis, anotherstructure of which is shown on page 20. These Poles, set on spans…
