Greene, Charles E[zra] 1842- [from old catalog], Greene, Albert Emerson. [from old catalog] · Ann Arbor, Mich., Printed for the author · leaf 161
vided the latter does not tooclosely approach the uniform compression value at the narrowerends. But if the strut is fixed at the ends, or is attached by a pinwhose diameter is large enough to make a considerable friction-moment, such enlargement at the middle is useless; for an equallylarge value… … COLUMNS. 149 stress found in the extreme fibre on the concave side must bedue to three combined effects:— 1st. The stress due to the load P, or/o = P ^ S. Fig. 61. 2d. The stress due to the resisting moment set up by Pj/q . 3d. The stress due to the resisting moment set up by Vv^ . From § 137,/=…
Mechanics, Applied · Strength of materials
