r side of A B, it willagree with/.,, and be negative or tension. If A B is takenmuch more steeply inclined, such will be the case. The smallprisms illustrate the constructions. If R O falls on A B, itwill be shear. Some constructions for different inclinationsof plane A B will be helpful to an… … 190 STRUCTURAL MECHANICS. the axes of p^ and p.i. The ano^le N M R is thus double the angleMOD, since it is an exterior an^le at the vertex of an isoscelestriangle. Lay off M R =■ \{Px —A) in the direction of theaxis of greatest stress, and R O will be the desired unit stresson A B. If A is…
