Fig. 240. Fig. 240 exhibits a front view of a grinding machine,for straight and taper work, that revolves on two deadcenters. To obtain the best results, a great variety of tablework and wheel speeds are necessary; all speed changes areadaptation of the belt and cone, easily understood byoperators.… … Fig. 241. Fig. 241 is a front view and fig. 242 is a back view ofthe machine shown in fig. 240. From these views thearrangement of the machine can be easily understood.
