manner to the adjustable dies described on page 259. The Advanced Machinist. 261 KEYSEATING MACHINE. Fig. 278 shows a machine which will cut keyseats onany portion of a shaft, without removing it from its bear-ings ; the machine being firmly fastened to the shaft bytwo clamps, the cutter-head is… … Fig. 278. smooth bottoms. The machine is provided with an auto-matic feed while cutting, but this feed may be disengagedif desired, and the cutter-head fed by hand. Five milling cutters are used with each machine; by em-ploying one or more of which on spindle, keyseats of any of thefollowing sizes…
