1902 December 26, 1917 Aeronautical Engineering (Supplement to The Aeroplane) xii … Fig. 28.— Diagram of Water Cooling System. inlet to the pump is 50 mm. and the diameter of the outlet is 55 mm. The water enters at the top of ihc rear cylinder through th ; steel tube elbow, and as previously mentioned is deflected onto the exhaust passages of each cylinder. The pump spindle is…
Aeronautics -- Periodicals
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
